REPETIER SERVER MANUAL
REPETIER SERVER CODE

Switch between relative and absolute coordinates, e.g.Things you shouldn’t do during pause are: After you hit the continue button, the extruder will go back to the starting position. You can do this, because the host remembers the position, where the pause started. One thing you could do is move the object back with a G1 command.

In these cases you don’t want the extruder to stay over the object. Typical reasons for a pause are switching filament type or modifications on the printing object like adding nuts bevor enclosing it in filament.

REPETIER SERVER CODE

While the kill job is not so important, you might want some code for the pause case. After hitting the button, the matching script will be send to the printer. When sending a job to the printer you may want to kill the print or pause the job. Normally this start and end codes are set in the slicer settings. So if you store or send a job, this always means these three files together. The G-Code for your printer is the assembled data from “Start Code”+”G-Code”+”End Code”. If you hover over a button, you get a note box with the title if you hover.

REPETIER SERVER MANUAL

Script 1 to 5 can be selected in Manual Control. for calibration, … You can set these scripts in Printer Settings -> Scripts. You have the possibility to define some G-Code scripts for start, end, run on kill, run on pause and up to 5 scripts you can use and call for whatever you want, eg. Then you switch the printer configuration the files will change to the one stored in the this configuration! Predefined G-Code Scripts Only if the G-Code is selected, a file selector appears to select the place to store the data. These codes are saved as part of your current printer configuration, when you press the save button. All other selections are smaller codes, which are executed depending on their intention. This is the code generated by the slicer. After finishing a slice, the “G-Code” is selected. The G-Code editor has it’s own small toolbar, where you can select the most important functions. If you want to edit the G-Code, click Edit G-Code. You will get a rendered preview image and you can start the print job from the host via the Server tab or in Repetier-Server. Save to Server: If the host is connected to Repetier-Server, you can save the G-Code in Repetier-Server.If the SD card is in the printer, you need to save the G code via the tab SD Card. The SD card should be in the computer, which is significantly faster than when the SD card is in the printer. If your printer runs with Repetier-Firmware, you can save it in binary format.

Save for SD Print: Here you save the G-Code for SD Print including additional start- and endcodes and job finishing commands, that are stored in printer settings.

Safe to File: Click here to save the generated G-Code on your hard drive without additional start- and endcodes, that are stored in printer settings.

If the host is connected via Repetier-Server, the G-Code is sent to the server and then the print job will start, so that you can close the host.

Print: This will start the print job directly.

If everything is OK, you can save the G-Code or start the print job with this commands: So you can check if everything is correct before printing, what can save a lot of time and money. You can rotate and inspect the whole model, a layer range or just single layers and you can visualize the travel moves. After slicing you can see the slicing result.
